HP SN3000B Reference Guide

Table 18 Serial cable pinouts (continued)
DescriptionSignalPin
N/ANot supported7
N/ANot supported8
AG default port mapping
Table 19 (page 50) lists the port mappings of F_Ports to N_Ports.
Table 19 HP SN6000B 16Gb FC Switch AG default port mapping
Default port mappingN_PortsF_PortsTotal ports
0–4 mapped to 4040–470–3948
5–9 mapped to 41
10–14 mapped to 42
15–19 mapped to 43
20–24 mapped to 44
25–29 mapped to 45
30–34 mapped to 46
35–39 mapped to 47
Table 20 HP SN3000B 16Gb FC Switch AG default port mapping
Default port mappingN_PortsF_PortsTotal ports
0, 1 mapped to 1616–230–1524
2, 3 mapped to 17
4, 5 mapped to 18
6, 7 mapped to 19
8, 9 mapped to 20
10, 11 mapped to 21
12, 13 mapped to 22
14, 15 mapped to 23
