General specifications
Table 14 HP SN6000B 16Gb FC Switch general specifications
DescriptionSpecification
F_Port, E_Port, M_Port, EX_Port, and D_PortConfigurable port types
Nonblocking shared-memory switchSystem architecture
PowerPC 440EPx at 667 MHzSystem processor
FC-PHANSI FC protocol
FC Class 2 and Class 3Modes of operation
Complies with FC-SW-3 Rev. 6.6Fabric initialization
Complies with FC-IP 2.3 of FCA profileFC-IP
768 Gb/sAggregate switch I/O bandwidth
Less than 700 ns with no contention (destination port is free)FC port-to-port latency
420 million frames per second (for Class 2, Class 3, and Class F frames for
the 48 port chassis)
Aggregate switching capacity
Table 15 HP SN3000B 16Gb FC Switch general specifications
DescriptionSpecification
F_Port, E_Port, M_Port, EX_Port, and D_PortConfigurable port types
Nonblocking shared-memory switchSystem architecture
PowerPC 440EPx at 667 MHzSystem processor
FC-PHANSI FC protocol
FC Class 2 and Class 3Modes of operation
Complies with FC-SW-3 Rev. 6.6Fabric initialization
Complies with FC-IP 2.3 of FCA profileFC-IP
384 Gb/sAggregate switch I/O bandwidth
800 ns with no contention (destination port is free)FC port-to-port latency
An aggregate switching capacity of 210 million frames per second (for Class
2, Class 3, and Class F frames for the 24 port chassis)
Aggregate switching capacity
Data transmission ranges
Table 16 Supported optics, speeds, cables, and distances (SFP+)
Single Mode
Media (9 microns)
Multimode
media (50
microns) (OM4)
Multimode media
(50 microns)
(OM3)
Multimode
media (50
microns) (OM2)
Multimode
media(62.5
microns) (OM1)Speed
Transceiver
type
N/A400 m (1,312
ft)
380 m (1,264 ft)150 m (492 ft)70 m (229 ft)4 Gb/sSWL
N/A190 m (623 ft)150 m (492 ft)50 m (164 ft)21 m (68 ft)8 Gb/s
N/A550 m (1,804
ft)
300 m (984 ft)82 m (269 ft)33 m (108 ft)10 Gb/s
N/A125 m (410 ft)100 m (328 ft)35 m (115 ft)15 m (49 ft)16 Gb/s
10 km (6.2 mi)N/AN/AN/AN/A8 Gb/sLWL
48 Specifications
