Bottom cover
NOTE: The bottom cover spare part does not include the rubber foot. The rubber kit spare part number is
L15592-001.
Description Spare part number
Bottom cover in Dark Ash Silver L15591-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the bottom cover, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
Remove the bottom cover:
1. Remove the rubber foot covering four of the screws that secure the bottom cover to the computer (1).
2. Remove the four Phillips PM2.0×10.0 screws (2).
3. Remove the two Phillips PM2.0×3.5 screws (3).
Component replacement procedures 29
