Battery
Description Spare part number
6-cell, 84-WHr, 3.7-Ahr, Li-ion battery 928372-855
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the battery, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29).
Remove the battery:
1. Disconnect the battery cable from the system board (1).
2. Remove the ve Phillips PM2.0×3.5 screws (2) that secure the battery to the computer.
3. Lift the battery out of the computer (3).
Reverse this procedure to install the battery.
Component replacement procedures 31
