Power connector cable
Description Spare part number
Power connector cable L15586-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the power connector cable, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29), and then remove the following components:
a. Battery (see Battery on page 31).
b. Rear speakers (see Rear speakers on page 55).
c. USB daughter board (see USB daughter board on page 39).
d. Solid state drive (see Solid state drive on page 49).
e. System board (see System board on page 52).
Remove the power connector cable:
1. Release the power connector cable from the routing path clips (1).
2. Remove the Phillips PM2.0×3.5 screw (2).
Component replacement procedures 57
