Rear speakers
NOTE: The speaker spare part kit includes all four speakers.
Description Spare part number
Speaker kit L15590-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the Rear speakers, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29), and then remove the following components:
a. Battery (see Battery on page 31).
b. System board mylar (see Left fan on page 45).
c. Left fan (see Left fan on page 45).
d. Right fan(see Right fan on page 47).
e. System board (see System board on page 52).
Remove the rear speakers:
1. Remove the two Phillips PM2.0×3.5 screws (1) that secure the speakers to the keyboard/top cover.
2. Remove the two Phillips PM2.0×2.0 screws (2) that secure the speakers to the keyboard/top cover.
3. Release the left rear speaker cable from the retaining clips (3).
Component replacement procedures 55
