LIP(F8,AL_PS) Denotes a loop failure detected by the L_port identified by AL_PS.
LIP(F8,F7) A loop initialization primitive frame used to indicate that a Loop Failure
has been detected at its receiver and does not have a valid AL_PA.
Login Count Number of device logins that have occurred on the switch.
Logout Count Number of device logouts that have occurred on the switch.
Long Frame Count Number of incidents in which one or more frames greater than the
maximum size (2,136 bytes) are received.
Loop Timeouts Number of loop timeouts. The Loop timeout value (LP_TOV) is 22 seconds.
LP_TOV is used to keep a Loop from deteriorating due to protocol errors or
lost Ordered Sets.
Loss Of Sync Number of synchronization losses (>100 ms) detected by this port. A loss
of synchronization is detected by receipt of an invalid transmission word.
Primitive Sequence Errors Number of invalid transitions made in the Link State Machine. Primitives
are recognized words that are not data words.
Rx Link Resets Number of link resets received from a device.
Rx Offline Sequences Number of offline sequence primitives received by the port.
Short Frame Count Number of incidents in which one or more frames smaller than the
minimum size (24 bytes) are received.
Total Errors Total number of primitive and non-primitive port link errors.
Total Link Resets Number of link-reset primitives transmitted and received by the port.
Total LIPs Received Number of loop initialization primitive frames received.
Total LIPs Transmitted Number of loop initialization primitive frames transmitted.
Tx Offline Sequences Number of offline primitives transmitted by the port.
Total Rx Frames Total number of frames received by the port.
Total Rx Words Total number of words received by the port.
Total Tx Frames Total number of frames transmitted by the port.
Total Tx Words Total number of words transmitted by the port.
TotalRXErrors Total number of errors received by the port.
TotalTXErrors Total number of errors transmitted by the port.
Tx Link Resets Number of link reset primitives sent from this port to an attached port.
Total Offline Sequences Total number of offline sequences transmitted and received by the port.
Table 19 Port Statistics data window fields (Continued)
Field Description
