HP StorageWorks XP10000

XP10000 hardware 25
Figure 3 shows the major components within each XP10000 rack.
Figure 3. Primary and second racks and major internal components
Disk Controller
Basic Disk
Chassis R0
(60 drives)
Expansion Disk
Chassis R1
(60 drives)
Expansion Disk
Chassis R3
(60 drives)
Expansion Disk
Chassis R2
(60 drives)
Primary Rack
Second Rack
Front View
