HP StorageWorks XP10000 Owner's Guide

Troubleshooting 59
Failure detection and reporting process
If a failure occurs in the disk array, the failure is detected and reported to
the system log, the SIM log, and the HP STC, as shown in Figure 7 and
explained in Table 8 (page 59).
Figure 7. Failure detection and reporting process
Table 8. Failure detection and reporting process
Item Description
1 A failure is detected in the disk array.
2 The failure is reported to the system.
3 The system stores the failure information in the system log.
4 The generated SIMs are stored on the disk array for use by HP
support representatives, and logged on the management server as
remote SIMs (R-SIMs).
If the disk array is not set up to “phone home,” when a SIM is
generated, the amber message LED on the disk array control panel
turns on. Call HP to determine the reason for the message.
