64 Business Copy XP (BC) for the XP10000/XP12000
• SvolMode (LUN(S)): CU:LDEV of the S-VOL
NOTE: An LDEV number ending with # (for example, 00:01#) indicates the LDEV is an external
volume.
• Type: Emulation type of the P-VOL and S-VOL
• Capacity (MB): Volume capacity displayed in megabytes (MB)
• CLPR(P): Cache logical partition of the P-VOL
• CLPR(S): Cache logical partition of the S-VOL
Window options
Copy Pace list
Use this list to select the copy pace (Slower, Medium, or Faster) for all pairs you are splitting. The Set
button applies the same copy pace to all pairs you are splitting.
Select MU list
Use this list to select the MU number for each pair being created: 0, 1, and 2 for L1 pairs, and 1 and 2 for
L2 pairs.
NOTE: You can select an MU number for a cascade pair. You cannot select the same MU number for
different cascade pairs of the same P-VOL (root or node volume).
Select Split Type list
Use this list to select the pairsplit type: Quick Split or Steady Split.
Select S-Vol box
This box filters S-VOLs displayed in the S-VOL list.
• Port: Display available S-VOLs by port.
• Volume Type:
• Internal Vol: Select available S-VOLs that are internal volumes.
• External Vol: Select available S-VOLs that are external volumes.
NOTE: You can only select external volumes when External Storage XP is available.
• Attribute: Select available S-VOLs that are reserved when the Reserved check box is selected, or that
are unreserved when the Not Reserved check box is selected. You can also select pairs that can be set
as L2 pairs when the Pair check box is selected.
NOTE: The number of secondary volumes that can be displayed in the S-VOL List at one time is limited to
1,024. If the number of volumes defined in the disk array exceeds this limit, use the Previous and Next
buttons on the upper right of the S-VOL List to turn the pages of the S-VOL List and see the entire list.
• Previous button: Returns to the previous page of the S-VOL List. This button is selectable only when the
number of volumes defined in the disk array exceeds 1,024, which is the maximum number of volumes
that can be displayed on one page. The button is unavailable if the total number of volumes defined in
the disk array is less than 1,024.
• Next button: Turns to the next page of the S-VOL List. This button is selectable only when the number of
volumes defined in the disk array exceeds 1,024, which is the maximum number of volumes that can
be displayed on one page. The button is unavailable if the total number of volumes defined in the disk
array is less than 1,024.
