Rack Installation
231U Rackmount Tape Enclosure Reference Guide
Note: Refer to“Internal cable configurations” on page 33 for details on configuring
one or two SCSI buses in the enclosure.
6. Plug the external SCSI cable from the SCSI controller to the appropriate
connector(s) on the rear panel of the enclosure. See Figure 13.
Note: Daisy-chaining of two or more 1U Rackmount Tape Enclosures is not supported.
7. Plug the AC power cord into the power cord connector, then into a grounded
outlet. See Figure 13.
Figure 13: Connecting the power and SCSI cables to the tape enclosure
8. Install the cable support clip(s) at the back of the rack rail(s) on one or both
sides of the enclosure. See Figure 14.
