HPE StoreOnce 4500/4700 (24TB) and 4500 (48TB)
Expansion Modules
The two HPE StoreOnce Expansion Modules use the same storage enclosure, but their hard drive
capacity is different. The StoreOnce 4500/4700 (24TB) Expansion Module contains twelve 2TB hard
disks. The StoreOnce 4500 (48 TB) Expansion Module contains twelve 4TB hard disks.
NOTE:
The disks in the server unit are different from the disks in the expansion shelf. Be sure to order the correct
replacement disk for the location where the disk has failed.
This is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers, check
the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the online source,
use the feedback form to log the problem: http://partsurfer.hpe.com/ContactUs.aspx.
Table 6: HPE StoreOnce 4500/4700 24TB Capacity Upgrade Kit spares part
numbers
Part Description SPNr
Fan module Fan assembly for HP D2700 and D2600 Disk
Enclosure
519325-001
Power supply (two per unit) Hot-plug power supply—460 watts, high efficiency
(HE), common slot
511777-001
I/O module Controller board—SAS, Input-Output (I/O) module 519316-001
Hard disk backplane Backplane board for HP D2600 Disk Enclosure—
includes 12 slots for Serial Attached SCSI (SAS)
disks
519317-001
Hard disks (12 per 4500/4700
24TB unit)
2TB 6G SAS MDL HDD 743403-001
Hard disks (12 per 4500 48TB
unit)
SPS-DRV HD 4TB 6G 7.2K 3.5 SAS MDL STOR 743405-001
SAS cable, from RAID controller
to the first shelf (and second shelf
to second RAID controller for
4700)
SPS-CA EXT HYB MSAS HD TO MSAS 717429-001
SAS cable, from expansion shelf
to expansion shelf
SPS-CA,EXT MINI SAS, 0.5M 408765-001
HPE StoreOnce 2900 24 TB Backup
The following table lists the spare parts for the main components in the server unit.
NOTE: Storage expansion is only possible by adding a further six disks to the server unit.
12 HPE StoreOnce 4500/4700 (24TB) and 4500 (48TB) Expansion Modules
