2. Slide the HP StoreOnce Backup system into position in the rack and secure it to the rack rails.
• HP StoreOnce 4420/4430 Backup system: Ensure the appliance clicks into place with
the retaining latches on the unit's front bezel.
• HP StoreOnce 4220/4210 and 2620 Backup system: Secure the appliance to the rack
rails using thumbscrews on the unit's front bezel.
IMPORTANT: The label on the top of the HP StoreOnce Backup system contains useful identity
information, such as the MAC address and default network name. Make a note of this
information before you install the HP StoreOnce Backup system in the rack. On HP StoreOnce
2620 Backup systems there is also a pull-out strip in the front panel with the serial number
and port ID.
Figure 1 Secure the HP StoreOnce 2620 Backup system to the rack
Figure 2 Secure the HP StoreOnce 4220/4210 Backup system to the rack
10 Installing and cabling the HP StoreOnce Backup system
