Using HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unified Extensible Firmware Interface (UEFI) that allows you to run
diagnostic tests to determine whether the computer hardware is functioning properly. The tool runs outside
the operating system so that it can isolate hardware failures from issues that are caused by the operating
system or other software components.
To start HP PC Hardware Diagnostics UEFI:
1. Turn on or restart the computer, quickly press esc, and then press f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB drive
NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see Downloading
HP PC Hardware Diagnostics (UEFI) to a USB device on page 47.
b. Hard drive
c. BIOS
2. When the diagnostic tool opens, use the keyboard arrow keys to select the type of diagnostic test you
want to run, and then follow the on-screen instructions.
NOTE: If you need to stop a diagnostic test, press esc.
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device
NOTE: Instructions for downloading HP PC Hardware Diagnostics (UEFI) are provided in English only.
There are two options to download HP PC Hardware Diagnostics to a USB device:
Option 1: HP PC Diagnostics homepage— Provides access to the latest UEFI version
1. Go to http://hp.com/go/techcenter/pcdiags.
2. Click the UEFI Download link, and then select Run.
Option 2: Support and Drivers page—Provides downloads for a specific product for earlier and later
versions
1. Go to http://www.hp.com.
2. Point to Support, located at the top of the page, and then click Download Drivers.
3. In the text box, enter the product name, and then click Go.
– or –
Click Find Now to let HP automatically detect your product.
4. Select your computer model, and then select your operating system.
5. In the Diagnostic section, click HP UEFI Support Environment.
– or –
Click Download, and then select Run.
Using HP PC Hardware Diagnostics (UEFI) 47

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Stream 11 Pro and is the answer not in the manual?

HP Stream 11 Pro Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack, Grey
Country of originChina
SteppingC0
Tjunction100 °C
Processor cache1 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Celeron®
Processor seriesIntel Celeron Processor N2000 Series for Mobile
Processor socketBGA 1170
Processor codenameBay Trail
Processor frequency2.16 GHz
Processor cache typeL2
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.58 GHz
Processor operating modes32-bit, 64-bit
ECC supported by processorNo
PCI Express configurations1x4
Thermal Design Power (TDP)7.5 W
Scenario Design Power (SDP)4.5 W
Maximum number of PCI Express lanes4
Motherboard chipset-
Internal memory2 GB
Memory clock speed1333 MHz
Memory form factorOn-board
Internal memory typeDDR3L-SDRAM
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Storage mediaSSD
Card reader integratedYes
Total storage capacity32 GB
Compatible memory cardsSD, SDHC, SDXC
Number of SSDs installed1
Display surfaceMatt
Display diagonal11.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency311 MHz
On-board graphics card burst frequency792 MHz
Audio systemDTS Studio Sound
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 8.1
Operating system architecture64-bit
Processor codeSR1YJ
Processor ARK ID82103
Processor package size25 x 27 mm
Intel Smart Connect Technology version1.00
Battery capacity37 Wh
Battery life (max)- h
Number of battery cells3
AC adapter power45 W
Sustainability certificatesEPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth205.7 mm
Width300 mm
Height19.7 mm
Weight1280 g
