9 Statement of memory volatility
The purpose of this chapter is to provide general information regarding nonvolatile memory in HP Business
Notebook PCs. This chapter also provides general instructions for restoring nonvolatile memory that can
contain personal data after the system has been powered off and the hard drive has been removed.
HP Business Notebook PC products that use Intel®-based or AMD®-based system boards contain volatile DDR
memory. The amount of nonvolatile memory present in the system depends upon the system configuration.
Intel-based and AMD-based system boards contain nonvolatile memory subcomponents as originally
shipped from HP, assuming that no subsequent modifications have been made to the system and assuming
that no applications, features, or functionality have been added to or installed on the system.
Following system shutdown and removal of all power sources from an HP Business Notebook PC system,
personal data can remain on volatile system memory (DIMMs) for a finite period of time and will also remain
in nonvolatile memory. Use the steps below to remove personal data from the notebook PC, including the
nonvolatile memory found in Intel-based and AMD-based system boards.
NOTE: If your tablet has a keyboard base, connect to the keyboard base before beginning steps in this
chapter.
1. Follow steps (a) through (j) below to restore the nonvolatile memory that can contain personal data.
Restoring or reprogramming nonvolatile memory that does not store personal data is neither necessary
nor recommended.
a. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup
Menu” message is displayed at the bottom of the screen.
NOTE: If the system has a BIOS administrator password, enter the password at the prompt.
b. Select Main, select Restore Defaults, and then select Yes to load defaults.
c. Select the Security menu, select Restore Security Level Defaults, and then select Yes to restore
security level defaults.
d. If an asset or ownership tag is set, select the Security menu and scroll down to the Utilities menu.
Select System IDs, and then select Asset Tracking Number. Clear the tag, and then make the
selection to return to the prior menu.
e. If a DriveLock password is set, select the Security menu, and scroll down to Hard Drive Tools
under the Utilities menu. Select Hard Drive Tools, select DriveLock, then uncheck the checkbox
for DriveLock password on restart. Select OK to proceed.
f. If an Automatic DriveLock password is set, select the Security menu, scroll down to Hard Drive
Tools under the Utilities menu. Select Hard Drive Tools, scroll down to Automatic DriveLock,
then select the desired hard drive and disable protection. At the automatic drive lock warning
screen, select Yes to continue. Repeat this procedure if more than one hard drive has an Automatic
DriveLock password.
g. Select the Main menu, and then select Reset BIOS Security to factory default. Click Yes at the
warning message.
h. Select the Main menu, select Save Changes and Exit, select Yes to save changes and exit, and
then select Shutdown.
52 Chapter 9 Statement of memory volatility

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Stream 11 Pro and is the answer not in the manual?

HP Stream 11 Pro Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack, Grey
Country of originChina
SteppingC0
Tjunction100 °C
Processor cache1 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Celeron®
Processor seriesIntel Celeron Processor N2000 Series for Mobile
Processor socketBGA 1170
Processor codenameBay Trail
Processor frequency2.16 GHz
Processor cache typeL2
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.58 GHz
Processor operating modes32-bit, 64-bit
ECC supported by processorNo
PCI Express configurations1x4
Thermal Design Power (TDP)7.5 W
Scenario Design Power (SDP)4.5 W
Maximum number of PCI Express lanes4
Motherboard chipset-
Internal memory2 GB
Memory clock speed1333 MHz
Memory form factorOn-board
Internal memory typeDDR3L-SDRAM
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Storage mediaSSD
Card reader integratedYes
Total storage capacity32 GB
Compatible memory cardsSD, SDHC, SDXC
Number of SSDs installed1
Display surfaceMatt
Display diagonal11.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency311 MHz
On-board graphics card burst frequency792 MHz
Audio systemDTS Studio Sound
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 8.1
Operating system architecture64-bit
Processor codeSR1YJ
Processor ARK ID82103
Processor package size25 x 27 mm
Intel Smart Connect Technology version1.00
Battery capacity37 Wh
Battery life (max)- h
Number of battery cells3
AC adapter power45 W
Sustainability certificatesEPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth205.7 mm
Width300 mm
Height19.7 mm
Weight1280 g
