HP Stream 11 Pro User Manual

1 Product description
Category Description
Product Name HP Stream 11 Pro Notebook PC
Processor Intel® Celeron™ N2840 2.16-GHz (SC turbo up to 2.58-GHz) dual core processor (1333-MHz FSB,
1.0-MB L2 cache, 4.5 W) integrated system-on-chip (SoC)
Chipset Integrated SoC platform controller hub (OCH)
Graphics Internal graphics: Unified memory architecture
Intel HD Graphics
Support for HD decode, DX11, and HDMI
Panel 11.6-in, high-definition (HD), white light-emitting diode (WLED), AntiGlare (1366×768), flat (3.6
mm), SVA, low-voltage differential signalling (LVDS), 200 nits typical brightness
Memory Support for DDR3L 1333-MHz single channel (DDR3L 1600-MHz downgrade to DDR3L 1333-MHz)
Supports up to 2048-MB maximum on-board system memory (256-MB × 16 × 4 pieces)
Storage Support for 32-GB embedded MultiMedia Controller (eMMC) version 5.0
Optical drive DVD±RW SuperMulti Double-Layer Drive (9.5mm tray load, SATA, external USB optical drive)
Audio and video HP TrueVision HD slim webcam, 1280×720 by 30 frames per second; fixed (no tilt),
with activity LED
Dual digital microphone with appropriate echo-cancellation, noise-suppression software
Two speakers
DTS Studio Sound audio
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
Two built-in WLAN antennas
Support for the following WLAN modules:
●
Intel Dual Band Wireless-AC 3160 802.11 ac 1×1 WiFi + Bluetooth 4.0 Combo Adapter
●
Realtek RTL8723BE 802.11b/g/n 1×1 Wi-Fi + Bluetooth 4.0 Combo Adapter
External media cards HP 2-in-1 multiformat Digital Media Reader Slot with push-push technology. Reads data from
and writes data to digital memory cards such as Secure Digital (SD™).
Ports
●
AC adapter, HP Smart
●
Audio-in (mono microphone)/audio-out (stereo headphone) combo jack
●
HDMI v1.4 supporting up to 1920×1080 @ 60Hz
●
RJ-45 (Ethernet)
●
USB: one USB 3.0 port, 2 USB 2.0 ports
Keyboard/pointing devices
(continued)
97%-size, textured, island-style, keyboard
Touchpad requirements:
Multitouch gestures enabled
1

HP Stream 11 Pro Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Country of origin	China
Stepping	C0
Tjunction	100 °C
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Celeron®
Processor series	Intel Celeron Processor N2000 Series for Mobile
Processor socket	BGA 1170
Processor codename	Bay Trail
Processor frequency	2.16 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.58 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	1x4
Thermal Design Power (TDP)	7.5 W
Scenario Design Power (SDP)	4.5 W
Maximum number of PCI Express lanes	4
Motherboard chipset	-
Internal memory	2 GB
Memory clock speed	1333 MHz
Memory form factor	On-board
Internal memory type	DDR3L-SDRAM
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	32 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	311 MHz
On-board graphics card burst frequency	792 MHz
Audio system	DTS Studio Sound
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Processor code	SR1YJ
Processor ARK ID	82103
Processor package size	25 x 27 mm
Intel Smart Connect Technology version	1.00
Battery capacity	37 Wh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	205.7 mm
Width	300 mm
Height	19.7 mm
Weight	1280 g
