HP TOUCHSMART TM2 Maintenance And Service Guide

1 Product description
Category Description
Product Name HP TouchSmart tm2 Notebook PC
Processors Intel™ Core™ i5-430UM 1.20-GHz turbo processor (800-MHz FSB, 3-MB L2
cache, 18-W)
Intel Core i3-330UM 1.20-GHz processor (800-MHz FSB, 3-MB L2 cache, 18-W)
Intel Pentium™ U5400 1.20-GHz processor (800-MHz FSB, 2-MB L2 cache, 18-W)
Chipset Intel HM55 Express chipset
Graphics ATi Mobility Radeon HD5450 4550 (ATI Park Pro) graphics subsystem with at least
512-MB of dedicated video memory
Support for Blu ray and/or high-definition (HD)-DVD playback with HD decode and
DX11 and HDMI support
Panels 12.1-inch, WXGA (1280 × 800, 16:10 wide aspect ratio), LED BrightView with
Wacom touch-screen (multitouch enabled) and EMR support
Typical brightness: 200 nits
Memory
●
Two SODIMM slots
●
Customer accessible/upgradable
●
Dual-channel support
●
DDR3, 1333-MHz, can be downgraded to 800-MHz
8192-MB total system memory (4096 MB × 2, dual-channel)
6144-MB total system memory (4096 MB + 2048 MB)
4096-MB total system memory (4096 MB × 1; 2048 MB × 2, dual-channel)
3072-MB total system memory (2048 MB + 1024 MB)
2048-MB total system memory (2048 MB × 1; 1024 MB × 2, dual-channel)
Hard drives
●
Supports all 9.5-mm, 6.35-cm (2.5-inch) hard drives
●
Serial ATA
●
Supports Accelerometer hard drive protection
640-GB, 5400-rpm
ENWW 1

HP TOUCHSMART TM2 Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	1.33 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	18 W
CPU multiplier (bus/core ratio)	10
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
Internal memory	3 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Display diagonal	12.1 \
Touch technology	Multi-touch
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Ethernet interface type	Gigabit Ethernet
Operating temperature (T-T)	41 - 95 °F
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	166 MHz
On-board graphics card dynamic frequency (max)	500 MHz
Audio system	Dolby Advanced
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit LAN, WLAN
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Keyboard layout	-
Pointing device	Clickpad
Operating system installed	Windows 7 Home Premium
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Country of origin	China
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Cable lock slot type	Kensington
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Processor code	SLBSL
Processor ARK ID	50028
Processor package size	BGA 34 x 28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2

Weight and Dimensions

Depth	326 mm
Width	230 mm
Weight	1893 g
Height (rear)	30 mm
Height (front)	24.3 mm
