English 3
1 Setting Up and Using Your PC
Connecting the Mouse, Keyboard, Monitor and Printer
Connecting the Mouse, Keyboard, Monitor and Printer
Connect the mouse, keyboard, monitor and printer to the back of the
computer. The connectors are shaped to go in one way only.
For more information on connecting the printer to your PC, refer to the
manual the came with the printer.
Desktop PC
The connectors are color-coded for easy matching. Match the colors.
Keyboard
(To connect an HP multimedia
Mouse
25-pin Parallel Connector
USB
1
Two 9-pin
Serial
Connectors
Monitor
keyboard, refer to page 6.)
B
A
1. USB is supported by: a) the latest version of Windows 95 (preloaded on some models); b) Windows 98.
gap.bk : gap-1.fb4 Page 3 Friday, January 15, 1999 5:03 PM
