HP Z220 SFF - 2 Workstation Features; HP Z220 SFF Workstation

HP Z220 SFF Workstation front panel components
Figure 1-1 Front panel components
Table 1-1 Component description
1 Optical drive 5
Optional media card reader (shown)
or optional second hard disk drive
2
Power button 6
Hard drive or optical drive activity
light
3
USB 2.0 ports (4, black) 7 Headphones connector
4
Microphone or headphones connector
(software selectable, default mode is
microphone)
2 Chapter 1 Hardware overview
