Table 4-4 Audio problems (continued)
Problem Cause Solution
Noise or no sound comes out of
the speakers or headphones.
1. If you are using digital speakers that have a stereo
jack and you want the system to autoswitch to digital,
use a stereo-to-mono adapter to engage the auto
sense feature, or use multimedia device properties
to switch the audio signal from analog to digital.
2. If the headphones have a mono jack, use the
multimedia device properties to switch the system to
analog out.
NOTE: If you set digital as the Output Mode, the
internal speaker and external analog speakers no
longer output audio until you switch back to an auto
sense or analog mode.
If you set analog as the Output Mode, external digital
speakers do not function until you change the output
mode back to an auto-sense or digital mode.
Sound occurs intermittently. Processor resources are being
used by other open
applications.
Shut down all open processor-intensive applications.
Workstation appears to be locked
up while recording audio.
The hard disk might be full. 1. Before recording, be sure there is enough free space
on the hard disk.
2. Try recording the audio file in a compressed format.
Solving printer problems
Table 4-5 Printer problems
Problem Cause Solution
Printer does not print. Printer is not turned on and
online.
Turn the printer on and be sure it is online.
The correct printer driver for
the application is not installed.
1. Install the correct printer driver for the application.
2. Try printing using the MS-DOS command:
DIR C:\> [printer port]
Replace printer port with the address of the printer
used. If the printer works, reload the printer driver.
If you are on a network, you
might not have made a
connection to the printer.
Make the proper network connection to the printer.
Printer might have failed. Run printer self-test.
Printer does not turn on. The cables might not be
connected properly.
132 Chapter 4 Diagnostics and troubleshooting

HP Z220 SFF Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Thermal Design Power (TDP)	77 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	32
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HDA
Product type	Workstation
Motherboard chipset	Intel® C216
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	Quadro 600
Power supply type	AC
Power requirements	100 - 240V, 50/60Hz
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	Intel, NVIDIA
Maximum storage capacity	4 TB
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Number of displays supported (on-board graphics)	3
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Parallel ports quantity	-
Chassis type	SFF
Product color	Black
Country of origin	China
Operating system installed	Windows 7 Professional
Power supply	240 W
Processor ARK ID	65733
Intel TSX-NI version	0.00
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	- g
