Table C-3 HP Z820 Workstation system board designators (continued)
Designator Name on board Component
P85 SAS5 SAS/SATA Port 5
P86 SAS6 SAS/SATA Port 6
P87 SAS7 SAS/SATA Port 7
P93 FRNT FAN2 Front Fan 2 Header
P94 FRNT FAN1 Front Fan 1 Header
P125 LC1 Liquid Cooling Header 1
P126 LC0 Liquid Cooling Header 0
SW3 SW3 Rear Power Button/LED
SW50 CMOS Clear CMOS Button
XBT1 XBT1 Battery
XMM1 CPU0-DIMM8 CPU0 Memory DIMM8
XMM2 CPU0-DIMM7 CPU0 Memory DIMM7
XMM3 CPU0-DIMM6 CPU0 Memory DIMM6
XMM4 CPU0-DIMM5 CPU0 Memory DIMM5
XMM5 CPU0-DIMM1 CPU0 Memory DIMM1
XMM6 CPU0-DIMM2 CPU0 Memory DIMM2
XMM7 CPU0-DIMM3 CPU0 Memory DIMM3
XMM8 CPU0-DIMM4 CPU0 Memory DIMM4
XMM9 CPU1-DIMM1 CPU1 Memory DIMM1
XMM10 CPU1-DIMM2 CPU1 Memory DIMM2
XMM11 CPU1-DIMM3 CPU1 Memory DIMM3
XMM12 CPU1-DIMM4 CPU1 Memory DIMM4
XMM13 CPU1-DIMM8 CPU1 Memory DIMM8
XMM14 CPU1-DIMM7 CPU1 Memory DIMM7
XMM15 CPU1-DIMM6 CPU1 Memory DIMM6
XMM16 CPU1-DIMM5 CPU1 Memory DIMM5
184 Appendix C System board designators
