HP Z220 SFF Workstation components

This section describes the HP Z220 Small Form Factor (SFF) Workstation components.

For complete and current information on supported accessories and components for the computer, see

http://partsurfer.hp.com.

Z220 SFF Workstation front panel

Figure 2-1 Front panel components

Table 2-1 Component description

1 Optical drive 5

Optional media card reader (shown)

or optional second hard disk drive

Power button 6

Hard drive or optical drive activity

light

USB 2.0 ports (4, black) 7 Headphones connector

Microphone or headphones connector

(software selectable, default mode is

microphone)

8 Chapter 2 Workstation features

Questions and Answers:

Need help?

Do you have a question about the HP Z620 Series and is the answer not in the manual?

HP Z620 Series Specifications

General

Chipset	Intel C602
Memory	Up to 96GB DDR3 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro
Power Supply	800W
Operating System	Windows 7, Windows 8, Linux
Dimensions	17.5 x 44.4 x 46.4 cm (6.9 x 17.5 x 18.3 in)
Networking	Integrated Gigabit Ethernet
Processor Options	Intel Xeon E5-2600 series (up to 8 cores)
Expansion Slots	7 slots (PCIe x16, PCIe x8, PCIe x4, PCI)
