HP Z620 Series User Manual

HP Z820 Workstation components
HP Z820 Workstation front panel
Figure 2-9 Front panel components
Table 2-9 Component descriptions
1 Optical drive 5 USB 3.0 ports (2, blue)
2
Power button 6 Headphone connector
3
Hard drive activity light 7 Microphone connector
4
USB 2.0 port (1, black) 8 IEEE–1394a FireWire connector
16 Chapter 2 Workstation features

HP Z620 Series Specifications

General

Chipset	Intel C602
Memory	Up to 96GB DDR3 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro
Power Supply	800W
Operating System	Windows 7, Windows 8, Linux
Dimensions	17.5 x 44.4 x 46.4 cm (6.9 x 17.5 x 18.3 in)
Networking	Integrated Gigabit Ethernet
Processor Options	Intel Xeon E5-2600 series (up to 8 cores)
Expansion Slots	7 slots (PCIe x16, PCIe x8, PCIe x4, PCI)
