Autodesk Stone Direct uses hardware RAID to provide high performance, reliability, and protection against
data loss.
The following table outlines the drive sizes and maximum number of enclosures supported by each model
of Autodesk Stone Direct XR-series storage arrays.
Disk sizeMax number of XE enclosures per
XR enclosure
Storage model
146GB4XR 5402
146 GB or 300 GB4XR 5412
300 GB or 450 GB7XR 6412
450 GB7XR 6500
XR 6500 and XR 6412 arrays require a single XR RAID enclosure for 2-loop or 4-loop hardware RAID storage
configurations .
XR 5412 and XR 5402 arrays require a single XR RAID enclosure for 2-loop configurations, or two RAID
enclosures for 4-loop configurations.
These configurations may include additional XE expansion enclosures, up to the maximum number supported.
You can increase storage capacity by adding disk arrays.
A number of Stone Direct configurations will ensure optimal playback of the most demanding formats.
Expected PeformanceLoopsStorage Configuration
One 2-loop connectionStone Direct XR
■ One stream SD/HD 10-bit (32 chan-
nel/8-bits per channel audio), or
■ One stream 2K 12-bit unpacked (8
channel/8-bits per channel audio)
Two 2-loop connections (if permitted by
chassis)
– or –
Stone Direct XR plus Stone Direct
XE
■ Two streams SD/HD 10-bit (32 chan-
nel/8-bits per channel audio), or
■ One stream 2K 12-bit unpacked (8
channel/8-bits per channel audio)
One 2-loop connection
Two 2-loop connections (one per enclos-
ure)
2 x Stone Direct XR
■ Two streams SD/HD 10-bit (32 chan-
nel/8-bits per channel audio), or
■ One stream 2K 12-bit unpacked (8
channel/8-bits per channel audio)
Connecting the HP Z800 ATTO Fibre Channel Adapter
On HP Z800 workstations or Lustre Media Servers, connections to media storage are made using the ATTO
Celerity FC84-EN fibre channel adapter, located in slot five (top to bottom).
NOTE If you need more storage connections, you can also have your HP Z800 workstation configured with a
second ATTO fibre channel adapter in slot 1, instead of the GigE adapter.
30 | Chapter 6 Connecting Storage
