HP Z800 - Linux Master to Linux Emulator

Linux Master to Linux Emulator
1
6
2
7
3
8
4
9
5
1
6
2
7
3
8
4
9
5
WHT
BLK
BLK
RED
GND
2 -RX-
7 -RX+
8 -TX-
3 -TX+
8 -TX-
3 -TX+
2 -RX-
7 -RX+
4 - GND (SHIELD)
4 - GND (SHIELD)
PAIR1
PAIR2
VTR-Emulation Control Cable
Linux(AJA) Master Controlling Linux(AJA) Emulator
Linux(AJA) Master Linux(AJA) Emulator
OEM-2K: MALE DB9
OEM-LH: FEMALE DB9
OEM-2K: MALE DB9
OEM-LH: FEMALE DB9
RS-422
Linux Master to Linux Emulator | 47
