Cabling for additional enclosures
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
XR RAID Enclosure
0
!
0
!
FACTORY
USE ONLY
FACTORY
USE ONLY
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
To FC adapter on workstation / LMS (port 0)
To FC adapter (port 3)
To FC adapter (port 1)
To FC adapter (port 2)
Single XR 6412 RAID enclosure, 4 loops
NOTE In a 4-loop configuration with a XR 6412 RAID enclosure, you need a minimum of one XE expansion
enclosure attached to the XR RAID enclosure.
Connecting Storage Enclosures | 35
