applications if the hard drive becomes corrupted. HP Recovery Disc Creator can create two kinds of recovery
DVDs:
Windows 7 operating system DVD—Installs the operating system without additional drivers or
applications.
Driver Recovery DVD—Installs specific drivers and applications only, in the same way that the HP
Software Setup utility installs drivers and applications.
Creating recovery media
NOTE: The Windows 7 operating system DVD can be created only once. Thereafter, the option to create that
media will not be available after you create a Windows DVD.
To create the Windows DVD:
1. Select Start > All Programs > Productivity and Tools > HP Recovery Disc Creator.
2. Select Windows disk.
3. From the drop-down menu, select the drive for burning the recovery media.
4. Click the Create button to start the burning process. Label the disc after you create it, and store it in a
secure place.
After the Windows 7 operating system DVD has been created, create the Driver Recovery DVD:
1. Select Start > All Programs > Productivity and Tools > HP Recovery Disc Creator.
2. Select Driver disk.
3. From the drop-down menu, select the drive for burning the recovery media.
4. Click the Create button to start the burning process. Label the disc after you create it, and store it in a
secure place.
Backing up your information
You should create system repair media and your initial backup immediately after initial system setup. As you
add new software and data files, you should continue to back up your system on a regular basis to maintain a
reasonably current backup. You should also create Windows system repair media (select models only) which
can be used to start up (boot) the computer and repair the operating system in case of system instability or
failure. Your initial and subsequent backups allow you to restore your data and settings if a failure occurs.
You can back up your information to an optional external hard drive, a network drive, or discs.
Note the following when backing up:
Store personal files in the Documents library, and back it up regularly.
Back up templates that are stored in their associated directories.
Save customized settings that appear in a window, toolbar, or menu bar by taking a screen shot of your
settings. The screen shot can be a time-saver if you have to reset your preferences.
When backing up to discs, number each disc after removing it from the drive.
NOTE: For detailed instructions on various backup and restore options, perform a search for these topics in
Help and Support. To access Help and Support, select Start > Help and Support.
132 Chapter 12 Backup and recovery in Windows 7

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ZBook 17 G2 and is the answer not in the manual?

HP ZBook 17 G2 Specifications

General IconGeneral
Form factorClamshell
Product typeMobile workstation
Product colorBlack
Country of originChina
Bus typeDMI
SteppingC0
Tjunction100 °C
Processor cache6 MB
Processor cores4
Processor modeli7-4710MQ
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4700 Mobile series
Processor socketPGA946
Processor threads8
Processor codenameHaswell
Processor frequency2.5 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.5 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)47 W
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM87
Memory slots4x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory32 GB
Memory layout (slots x size)1 x 4 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsSD, SDHC, SDXC
Number of HDDs installed1
Display surface-
Display diagonal17.3 \
Display resolution1600 x 900 pixels
Native aspect ratio16:9
On-board graphics card ID0x416
Discrete graphics card modelNVIDIA® Quadro® K1100M
On-board graphics card modelIntel® HD Graphics 4600
Discrete graphics card memory2 GB
Discrete graphics memory typeGDDR5
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card base frequency400 MHz
On-board graphics card DirectX version11.2/12
On-board graphics card dynamic frequency (max)1150 MHz
Audio systemDTS Studio Sound
Number of built-in speakers2
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
HDMI ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Pointing deviceTouchpad
Recovery operating systemWindows 8.1 Pro
Operating system installedWindows 7 Professional
Processor codeSR1PQ
Processor ARK ID78931
Intel TSX-NI version0.00
Processor package size37.5 x 32 x 1.6 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version1.00
Battery capacity75 Wh
Battery life (max)- h
AC adapter power200 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth272 mm
Width416 mm
Height34 mm
Weight3410 g
