Keyboard

NOTE: The keyboard spare part kit includes a backlight and cable, pointing stick and cable, TouchPad and

cable, and the keyboard cable.

For use in country or region Spare part number For use in country or region Spare part number

For use in Belgium 733688-A41 For use in Northwest Africa 733688-FP1

For use in Brazil 733688-201 For use in Norway 733688-091

For use in Bulgaria 733688-261 For use in Portugal 733688-131

For use in Canada 733688-DB1 For use in Romania 733688-271

For use in the Czech Republic and Slovakia 733688-FL1 For use in Russia 733688-251

For use in Denmark 733688-081 For use in Saudi Arabia 733688-171

For use in France 733688-051 For use in Slovenia 733688-BA1

For use in Germany 733688-041 For use in South Korea 733688-AD1

For use in Greece 733688-151 For use in Spain 733688-071

For use in Hungary 733688-211 For use in Sweden and Finland 733688-B71

For use in Iceland 733688-DD1 For use in Switzerland 733688-BG1

For use in India 733688-D61 For use in Taiwan 733688-AB1

For use in Israel 733688-BB1 For use in Thailand 733688-281

For use in Italy 733688-061 For use in Turkey 733688-141

For use in Japan 733688-291 For use in the United Kingdom

and Singapore

733688-031

For use in Latin America 733688-161 For use in the United States 733688-001

For use in the Netherlands 733688-B31

Before removing the keyboard, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see Battery on page 45).

5. Remove the service cover (see Service cover on page 47).

6. Remove the optical drive (see Optical drive on page 56) or Upgrade Bay hard drive (see Upgrade Bay

hard drive on page 58).

Remove the keyboard:

1. Turn the computer upside down the front toward you.

Component replacement procedures 61

Questions and Answers:

Need help?

Do you have a question about the HP ZBook 17 G2 and is the answer not in the manual?

HP ZBook 17 G2 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Country of origin	China
Bus type	DMI
Stepping	C0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-4710MQ
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Mobile series
Processor socket	PGA946
Processor threads	8
Processor codename	Haswell
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	47 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM87
Memory slots	4x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	SD, SDHC, SDXC
Number of HDDs installed	1
Display surface	-
Display diagonal	17.3 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K1100M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	DTS Studio Sound
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Processor code	SR1PQ
Processor ARK ID	78931
Intel TSX-NI version	0.00
Processor package size	37.5 x 32 x 1.6 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	75 Wh
Battery life (max)	- h
AC adapter power	200 W
Sustainability certificates	ENERGY STAR
