HPE Aruba 2930F

1
2
3
4
5
6
Port LEDs: Off after self-test unless a network cable is connected and
the port is receiving link beat.
1
Global Status LED: Green after self-test in default configuration.2
Locator/Unit-Identification LED: Off after self-test.3
Speed Mode Selected LED: Off after self-test in default configuration.4
PoE Mode Selected LED (Only on Aruba 2930F models that support
PoE+ operation): Off after self-test in default configuration.
5
User Mode Selected: Off after self-test in default configuration.6
4. Disconnect the AC adapter from the switch and remove the power cord from the power
source.
Mounting the JL258A Aruba2930F 8–port switch
Supported mounting options for the Aruba 2930F 8G switch include:
• Rack mount
• Tabletop or desktop mount
• Under-table mount
• Wall mount
Mounting the JL258A Aruba2930F 8–port switch 7
