Installing a disk drive
CAUTION:
To prevent improper cooling and thermal damage, operate the enclosure only when either a disk
drive or a drive blank is installed in every bay.
Procedure
1. Remove the drive blank. Removing an SFF drive blank is similar to the example shown for the LFF
drive blank.
Figure 12: LFF disk drive blank
2. Unlatch the handle by pressing the button on the disk drive.
Figure 13: LFF handle release button
Figure 14: SFF handle release button
26 Installing a disk drive
