HTC 650 - Page 14

14
Parts list, HTC 650, grinding head cont.
No. Description Art. No. Qty
14
Nilos ring 6017 JV 110950 1
15 Bearing cup 110917 1
16 Ball bearing 6017-2RS1 C3 110951 2
17 Screw MC6S M8x120 galvanised 12.9 310235 2
18 Circlip SGA 85 310166 1
19 Belt upper HTC 650 poly-v 111296 1
20 Shaft journal HTC 650-950 110931 2
21 Screw M6S M10x30 galvanised 310066 4
22 Screw MC6S M8x20 12.9 310027 8
23 Gamma ring 9RB 25x42x04 110949
2
24
Washer BRB M10 galvanised 310048 4
25 Cover centre hub HTC 950 110921 1
26 Screw MF6S 8x30 galvanised 310182 8
27 Washer BRB M8 galvanised 310077 3
28 Screw MC6S M8x20 8.8 galvanised 310161 3
29 Screw MFT M5x12 galvanised 8.8 310141 6
30 Upper plate HTC 650 (-04)
111070 1
31
Screw MC6S M8x20 galvanised 310161 12
32 Screw M6S M10x30 galvanised 310066
2
33 Washer BRB M10 galvanised 310048 2
34 Screw M6S M16X30 galvanised 310170 1
35
Washer BRB M16 galvanised 310032 1
36
Washer BRB M8 galvanised 310077 3
37 Screw M6S M10x30 galvanised 310066
2
38
Washer BRB M10 galvanised 310048 2
39
Screw MC6S M12x1.25,20 310175 4
40 Screw M6S M10x30 galvanised 310066
2
41
Washer TBRSB 10.5x26 galvanised 310042 2
42 Lower Plate HTC 650 (-04)
110068 1
43 Shaft spacer HTC 950 110925 3
44 Axle belt tensioner, lower 110932 2
45 Ball bearing 6207 2rs C3
110078 8
46
Tensioning wheel HTC 950 110933 4
47 Circlip SGA 35 310038
4
48
Belt, inner HTC 650 EX/HDX 111369 1
49
Screw MF6S M6x20 10.9 galvanised 310013 16
50 Fixing boss HTC 650-950 110928 16
51 Edging strip HTC 650 (-04) 111069 1
52 Lifting eye LH M10 310253 2
53
Circlip SGH 100 310164 1
54
Shaft centre hub HTC 950 110913 1
55 Ball bearing 6013-2RS1 C3 110946 2
56 Spacer 28 HTC 950 110914 1
57 Circlip SGA 65 310163 1
58 Center hub 111077 1
59 Fitting bolt 16xM12x25 310167 2
60 Tensioning wheel plate, eccentric 110936 2
61 Spacer disk Hub HTC 950 110927 4
62 Shaft belt tensioner, eccentric 110935 2
63
Hub packet 111235 4
