Parts list HTC 950 grinding head
Exploded diagram, HTC 950 grinding head
No. Description Art. No. Qty
1 Screw M6S M16X30 galvanised 310170 4
2 Washer BRB 17x30x3 310171 4
4 Screw MC6S M8x20 8.8 galvanised 310161 6
3 Fixing lug HTC 950 110912 2
5 Screw M6S M8x16 galvanised 310192 3
6 Washer BRB M8 310077 3
7 Screw MC6S M8x70 galvanised 310074 2
8 Screw MFT M5x12 galvanised 310141 6
9 Screw M6S M10x30 galvanised 310066 2
10 Screw MC6S M8x20 8.8 galvanised 310161 8
11 Washer TBRB 22X10.5X4 310008 2
12 Radial seal CB 20x30x5 110948 2
13
Spacer disc belt tensioner HTC 950 110929 2
14 Screw MF6S 8x30 galvanised 310182
8
15 Cover centre hub HTC 950 110921 1
16 Gamma ring 9RB 25x42x04 110949 2
17 Shaft journal HTC 950 110931 2
18 Upper Plate HTC 950 110920 1
19
Washer TBRB 22X10.5X4 310008 2
20
Screw M6S M10x30 galvanised 310066 2
21
Belt upper HTC 950 110953 1
22
Ball bearing 6017-2RS1 110951 1
23
Ball bearing 6017-2RS1 110951 1
24
Bearing cup HTC 950 110917 1
25
Nilos ring HTC 950 110950 1
1
2
4
5
6
7
8
9
15
16
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
27
29
30
31
32
33
34
35
36
37
38
39
41
42
44
45
46
47
48
52
51
50
49
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
69
68
71
70
72
73
75
76
77
40
3
43
78
74
