19
No. Description Art. No. Qty
17 Nut nylock M6 galvanised DIN985 310072 4
18 Pump EH-C15VC-PR2-IPVC 111394 1
19 Screw MC6S MC6S M6x16 8.8 galvanised 310082 4
20 Rubber hose 1.5 m 111399 1
21 Cable clips 8 mm with M8 hole 111582 1
22 Filter VEF 0138T1B 111398 1
23
Nozzle cover 111487 1
24
Screw MC6S M6x12 8.8 310030 4
25 Washer BRB M6 galvanised 310012 2
26 Nozzle holder 111488 1
27 Nozzle RXT 0060 B1 111397 1
Parts list HTC 800 Mist Cooler System cont.
