Parts list, HTC 800, grinding head cont.
No. Description Art. No. Qty
19 Screw M6S M10x30 galvanised 310066 4
20 Washer TBRSB M10 galvanised 310042 4
21 Screw MC6S M6X20 12.9 310027 8
22 Gamma ring 9RB 25x42x04 110949 2
23
Screw MC6S M5x8 galvanised 310219 6
24 Upper plate HTC 800 (-04)
111082 1
25 Radial seal CB 20x30x5 110948 2
26 Spacer disc, belt tensioner HTC 950 110929 2
27 Screw MF6S 8x30 galvanised 310182 8
28 Cover centre hub HTC 950 110921 1
29 Washer BRB M8 galvanised 310077 3
30
Screw M6S M8x25 galvanised 310065 3
31 Screw M6S M16X30 galvanised 310170
1
32
Washer BRB M16 galvanised 310032 1
33 Screw MC6S M8x20 310161 6
34 Screw M6S M10x30 galvanised 310066 2
35
Washer BRB M10 galvanised 310048 2
36 Screw M6S M10x35 galvanised 310007
2
37
Washer BRB M10 galvanised 310048 2
38
Screw MC6S M8x20 8.8 galvanised 310161 12
39 Screw M6S M10x30 galvanised 310066
2
40
Washer BRB M10 galvanised 310048 2
41
Screw MC6S M6X10 8.8 galvanised 310005 4
42
Axle belt tensioner, lower HTC 950 110932 2
43 Ball bearing 6207 2rs C3 110078 8
44 Tensioning wheel HTC 950 110933 4
45 Circlip SGA 35 310038
4
46
Fitting bolt 16xM12x25 HTC 950 310167 2
47
Tensioning wheel plate, eccentric HTC 950 110936 2
48
Shaft belt tensioner, eccentric HTC 950 110935 2
49
Shaft spacer HTC 950 110925 3
50 Lifting eye LH M10 310253 2
51 Circlip SGH 100 310164 1
52 Shaft centre hub HTC 950 110913 1
53 Ball bearing 6013-2RS1 C3 110946
2
54
Spacer 28 HTC 950 110914 1
55 Circlip SGA 65 310163 1
56 Centre hub HTC 950 110916 1
57 Belt, inner HTC 950 110952 1
58 Edging strip HTC 800 (-04) 111067 1
59 Screw MF6S M6x20 10.9 galvanised 310013 16
60 Fixing boss HTC 650-950 110928 16
61 Spacer disc hub HTC 950 110927 4
62 Hub packet HTC 950 110962 4
63
Screw MC6S M12x1.25,20 310175 4
64
