27
No. Description Art. No. Qty
14
Wear protection upper HTC 950 111029 2
15 Screw MC6S M6X25 12.9 galvanised 310035 4
16 Washer BRB M6 310012 4
17 Ermaflex F76 mm Price/M 10284 1
18 Nut nylock M6 galvanised DIN985 310072 4
19 Screw MC6S M6X12 8.8 galvanised 310030 4
20 Washer BRB M6 310012 4
21 Branch pipe complete HTC 950 111015 1
22 Suction hose dia 63 mm 111158 1
23
Sprint chassis HTC 950 111023 2
24
Wheel HTC 950 110899 2
25 Adjustment bolt Lockable wheel 111036 2
26 Screw MC6S M8x20 8.8 galvanised 310161 8
27 Washer BRB M8 310077 8
28 Gas spring complete HTC 950 111039 2
29 Adjustment bolt Lockable 111037 2
30 Weight 14 kg left HTC 950
110982 1
30 Weight 14 kg right HTC 950
110981 1
31 Weight 35 kg HTC 950 110983
2
32
Screw MC6S M8x16 galvanised 310080 2
33 Wear protection lower HTC 950 111030 2
34 Washer BRB 26x45x4 310197 2
35
Bushing BM25 111133 2
36 Washer BRB 26x45x4 310197
2
37
Circlip SGA 25 310021 2
38
Sprint chassis HTC 950 111023 2
39
Bushing BM25 111133 2
40 Washer BRB 26x45x4 310197
2
41
Circlip SGA 25 310021 2
42
Screw MC6S M8x16 galvanised 310080 4
43 Hose large reinforced PVC HTC 950 111104 1
44 Grinding head HTC 950 RX™ Page 45 1
45
Machine cover HTC 950 111040 1
46 Velcro male width 38mm 110264
3
47
Washer BRB M8 310077 8
48
Screw MC6S M8x16 galvanised 310080 8
49
Extractor, grinding cover HTC 950 111012 2
50 Cover HTC 950 111044 1
51 Pop rivet 4.8X19 310083 4
Parts list, HTC 950 chassis cont.
