HTC 650 - Page 29

29
No. Description Art. No. Qty
18 Nut nylock M6 galvanised DIN985 310072 4
19 Fixing plate, pump 111445 1
20 Hose large reinforced PVC 1.1 m 110130 1
21 Nut Nylock M8 galvanised DIN985 310067 2
22 Washer BRB M8 galvanised 310077 2
23 Bushing 2531-1/2-1/4 111524
2
24 Hose connection 1511-6/4-1/4 111523
2
25 Screw MC6S M6x12 8.8 310030 6
26 Attachment, filter 111610 1
27 Screw MC6S M8x80 galvanised 310217 2
28 Filter VEH-0052-D2 111395 1
29 Filter XVE-H052-D21 (Extra) 111396
30
Rubber hose 1.50 m 111399 1
31
Cable clips 8 mm with M8 hole 111582 2
32
Decal, HTC Mist Cooler System 111585 1
33 Nozzle cover 111487 1
34 Filter VEF 0138T1B 111398 1
35
Washer BRB M6 galvanised 310012 2
36
Nozzle holder 111488 1
37
Nozzle RXT 0060 B1 111397 1
38 Pop rivet 4.8x12.7 310084
3
39
Holder nozzle cover 111489 1
Parts list HTC 950 Mist Cooler System cont.
