15 16
Witching between infrared thermal image and
visible image
Press “ ” or “ ” key to switch the degree of fusion between
inferred thermal images and visible images (the degree of fusion is 0%,
25%, 50%, 75% and 100%).
Image capture
Press the image capture key. When the capture is successful, the screen
will display “store photo?” prompt. If “yes” is selected, please press
“ /MENU” key to determine to save the image. If “no” is selected, press
“ SELECT/ENTER ” key to determine not to save the image.
In the normal boot operation interface, press and hold the capture button
and the screen will display the prompt “Record video?”, select “Yes” or
“No” to record, press “ ”“ ” to switch the selection, and then press
“SELECT/ENTER” to confirm , if you confirm the recording, you can
short press the capture button again to record, and after the recording is
completed, press and hold the capture button to end the recording
(for
HT-A10 products).
Video recording
The function to hide highest/lowest temperature
column at the screen bottom
Under the operation after normal start up, press “ ” key and the
screen bottom will display highest/lowest temperature column. Press
“ ” can also hide it.
Image output
The saved images through capture may be checked and output by
connecting with a computer through
Type-C USB
.
Read images
Open the USB protective cover as shown in . Use USB line to
connect the USB port and then computer to read the images or save it
into computers.images or save it into computers.
The supported operating system through verification includes: winxp,
win7, win 8, win10, Apple system.
It is suggested to use the attached USB line or USB line with higher
quality.
Note:
When connecting with a computer, pull off the data line after selecting
“pop out device safely” to avoid causing file system damage and other
problems. If “unable to save” and other problems occur, you may find the
hard disc in the computer and fix it.
2
