20220211-154307
20220211-124307
20220210-174307
20220210-164307
19 20
When viewing the video (if it is not playing) press the “ ” key the screen
will display “Delete video?” Select “Yes” or “No” to delete the video, press the
“ ”“ ” key to Switch the selection, then press the“SELECT/ENTER”
key to confirm.When the video is deleted, “No videos” will be displayed.
Press “SELECT/ENTER” to return to the menu and press “ /MENU” to exit
the menu.
3. Introduction to “Video” Submenu
3.1.View Video
Press “
/MENU
” key to enter the main menu, select “ ” in the main
menu(video), as shown below.
3.2. Delete Video
Press the “ ” key to enter the video list, press the “ ” and “ ”
keys in the navigation keys to select the video, and then press the
“SELECT/ENTER” key to view the video. When viewing a video (not
playing), press the “ ” key to view the previous video, and press the
“ ” key to view the next video.
Press the “
/MENU
” key to exit from the menu.
4. Introduction to “Color Palette” Sub-menu
4.1. Color Palette Description
The following is the image of the same object with selection of different
color palettes.
The palette can be used to change the pseudo-color display of the
infrared image on the display. Some tune Swatches are better suited
for specific applications and can be set up as needed. The palette is
divided into: rainbow, iron,
cold color
, white hot, black hot, five palettes.
These palettes work best with high thermal contrast and provide
additional color contrast between high and low temperatures.
Suitable selection of color palette displays the details of the target
objective better. Rainbow, iron and cold color palettes focus on display
of color. Such color palettes are very suitable for high heat contrast
and are used to improve the color contrast between high temperature
and low temperature. But the
White hot
and
Black hot
color palettes
provide even linear color.
IronRainbow Cold color
White hot Black hot
