HTP MODCON1000 Installation, Start-Up And Maintenance Instructions

LP-428 Rev. 6.6.16
55
LINE VOLTAGE E19
PUMP OFF
E19 indicates the line voltage frequency is
out of range. This could happen if the boiler
is being powered from a small gasoline
powered generator that is overloaded or not
functioning correctly.
Inspect power wiring to the boiler and repair as necessary.
If connected to line voltage, notify the power company. If
connected to an alternate power source such as a generator or
inverter, make sure the line voltage frequency supplied by the
device is 60 Hz.
Table 24 - Boiler Error and Fault Codes
Outdoor Sensor
(7250P-319)
Supply Temperature Sensor
(7250P-324)
Boiler Sensor
(7250P-667)
Indirect Sensor
(7350P-325)
Outside
Temperature
(
o
F)
Resistance
(ohms)
High / Low
Temp Sensor
Temp. (
o
F)
Resistance (Ohms)
-22 171800 32 32550
-13 129800 41 25340
-4 98930 50 19870
5 76020 59 15700
14 58880 68 12490
23 45950 77 10000
32 36130 86 8059
41 28600 95 6535
50 22800 104 5330
59 18300 113 4372
68 14770 122 3605
77 12000 131 2989
86 9804 140 2490
95 8054 149 2084
104 6652 158 1753
113 5522 167 1481
176 1256
185 1070
194 915
202 786
212 667
Table 25 - Sensor Temperature Resistance
Part 12 - Maintenance
A. Procedures
Periodic maintenance should be performed once a year by a
qualied service technician to assure that all the equipment
is operating safely and eciently. The owner should make
necessary arrangements with a qualied heating contractor
for periodic maintenance of the boiler. The installer must also
inform the owner that a lack of proper care and maintenance
of the boiler may result in a hazardous condition.
BEFORE EACH HEATING SEASON a trained and qualied
service technician should perform the inspections as per the
boiler inspection and maintenance schedule in this manual.
Failure to do so could result in death or serious injury.
The combustion chamber insulation in this product contains
ceramic ber material. Ceramic bers can be converted
to cristobalite in very high temperature applications. The
International Agency for Research on Cancer (IARC) has
concluded, “Crystalline silica inhaled in the form of quartz
or cristobalite from occupational sources is carcinogenic to
humans (Group 1).”
• Avoid breathing dust and contact with skin and eyes.
• Use a NIOSH certied dust respirator (N95). This type
of respirator is based on the OSHA requirements for
cristobalite at the time this document was written. Other
types of respirators may be needed depending on job
site conditions. Current NIOSH recommendations can
be found on the NIOSH website: http://www.cdc.gov/
niosh/homepage.html. NIOSH approved respirators,
manufacturers, and phone numbers are also listed on
this website.
• Wear long-sleeved, loose tting clothing, gloves, and eye
protection.
• Apply enough water to the combustion chamber lining
to prevent dust.
• Wash potentially contaminated clothes separately from
other clothing. Rinse clothes washer thoroughly.
NIOSH stated First Aid.
• Eye: Irrigate immediately.
• Breathing: Fresh air.
B. Combustion Chamber Coil Cleaning Instructions
*Before beginning this procedure, have on hand the following
items:
• a nylon, stainless steel, or brass brush (not steel)
• gloves and eye protection
1. Shut down the boiler by using the following steps:
a. Close the gas valve. Shut down the unit, and wait for it to
be cool to the touch.
b. Disconnect the condensate piping from the outside
connection, (not from the boiler side), so ow from
condensate reservoir can be observed.
c. Disconnect electrical connections from the gas valve, spark
electrode, ame rectication probe, and combustion blower.
d. Remove the four (4) screws on the aluminum ¾” NPT
connector on the right side of the gas valve.
e. Disconnect the wiring connected to the combustion blower
motor.
f. Remove the six (6) 10MM nuts from the burner plate
assembly.
g. Pull the entire burner plate assembly with blower still
attached towards you, while removing or pushing aside any
wiring to allow removal of the assembly.
2. Spray the coils liberally with a spray bottle lled with clear
tap water. Conne the spray to the area being cleaned. Avoid
getting the ceramic target wall wet. If the condensate system is
blocked, use a vacuum to clear it.
3. Scrub coils of any buildup with a nylon, stainless steel, or brass
brush. Do not use a steel brush. Vacuum the debris from the
coils.
