HUANUO HNDS8 - Step 8: Route Cables along the Arms

12
Step 8 Route Cables along the Arms
04
Screwdriver
[Not Included]
Secure the Cable Cover [04] to the arm [01] by
tightening the bolts [G] using screwdriver
Loosen the preassembled bolts [S] on the
arm [01] to detach the cable guide from the
arm [01], and keep the bolt for the use in
next step
Route the cables into the cable guide and
secure the cable guide by tightening the
bolts [S] using screwdriver
S
