HUANUO HNDS8 - Installation Steps Overview; Step 1: Install the Base

06
Secure the base to the desktop
4
Step 1 Install the Base
A. For Clamp Mounting
A-1 Install the C-Clamp
3
Connect part [Y] to part [X] according to the thickness of the desktop
OR
The first choice
X
Y
The second choice
X
Y
1
2
Warning:
Ensure bolts are
secured firmly.
5/32 in.
(4mm)
03
X
F
Connect part [X] to pole
assembly [03]
Detach the c-clamp entirely
X
Y
①
②
