No. Item Quantity
3 PG connector 2
4 M4x12 hexagon socket head
cap screw
4
5 Expansion bolt 2
6 Hose clamp 2
7 OT terminal
l M4: 2
l M6: 1
l M8: 1
8 Casting Adjustable-degree
solid
1
1
9 Quick Start Guide 1
Pay attention to the following:
l Only the AP8030DN carton contains the casting adjustable-degree solid.
l Figures in the document are for reference only and may be different from actual devices.
2.4 Determining the Installation Position
When determining the AP installation position, comply with the following rules:
l Do not install the AP in the place with high temperature, dust, noxious gas, or unstable
voltage, or in the place near flammable or explosive materials and interference sources such
as a large radar station, radio station, and transformer station.
l Install the AP in a site that is free from leaking or dripping water, heavy dew, and humidity,
and take protective measures to prevent water from flowing into the equipment along the
cable.
l Install the AP in a hidden position that does not affect daily lives and work of residents.
l Make the engineering design by fully considering such factors as hydrology, geology,
earthquake, electric power, and traffic. The selected site should comply with the
environment design specifications of communications equipment.
The AP8030DN and AP8130DN can be installed against a pole or a wall. The diameter of the
pole used should be from 48 mm to 114 mm. The AP must be installed by professional installation
personnel, and the installation position is determined according to the site survey.
Figure 2-2 and Figure 2-3 shows dimensions of the AP8030DN and AP8130DN.
Huawei AP8030DN & AP8130DN
Hardware Installation and Maintenance Guide
2 AP Installation
Issue 02 (2014-12-05) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
