The PuTTY Configuration window is displayed.
Step 2 In the navigation tree on the left, choose Connection > Serial.
Step 3 Set the login parameters.
Example:
l Serial Line to connect to: COMn
l Speed (baud): 115200
l Data bits: 8
l Stop bits: 1
l Parity: None
l Flow control: None
NOTE
n indicates the serial port number.
Step 4 Choose Session from the navigation tree.
Step 5 Select Serial for Connection type, as shown in Figure 6-3.
Figure 6-3 PuTTY Configuration
Step 6 Click Open.
The following information is displayed:
CX320 Switch Module
User Guide
6 Common Operations
Issue 09 (2019-08-02) Copyright © Huawei Technologies Co., Ltd. 89
