Slot Quanti
ty
Remarks
8 and 9 2 Slots for DC power modules in 1+1 backup mode
10 1 Slot for a fan module
1.1.3 CX600-X1-M4 Specifications
Chassis Specifications
Table 1-3 Physical specifications of the CX600-X1-M4
Item Specification
Dimensions (H x W x D) 132 mm x 442 mm x 220 mm (5.20 in. x 17.40 in. x 8.66 in.)
Installation Can be installed in an N63B cabinet, a 19-inch standard
cabinet, or a 23-inch rack that complies with the North
American standard
Weight Full configuration: 13 kg (28.67 lb)
Typical power consumption 350 W
Heat dissipation 1135 BTU/hour
DC input
voltage
Rated
voltage
-48 V
Maximum
voltage
range
-38 V to -72 V
System
reliability
MTBF
(year)
31.07
MTTR
(hour)
0.5
Ambient
temperature
Long-term Ordinary mode: 0°C to +45°C (32°F to 113°F)
Enhancement mode: -40°C to +65°C (-40°F to 149°F)
NOTE
The use of optical components may limit the ambient temperature
range.
Short-term -5°C to +55°C (23°F to 131°F) (Short-term refers to a period
of not more than 96 consecutive hours and a total of not more
than 15 days in 1 year.)
Remarks Temperature change rate limit: 30°C/hour (86°F/hour)
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description 1 CX600-X1-M4 Hardware Description
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
