Table 3-20 Description of the buttons and indicators on the NPU panel
Indicator/
Button
Description
STAT
indicator
If the indicator is steady green, the NPU is working properly.
If the indicator is steady red, the hardware of the NPU is faulty.
If the indicator blinks green, theNPU is being registered.
If the indicator is off, the NPU is not powered on or fails to be registered.
ACT
indicator
If the indicator is steady green, the NPU is in the master state.
If the indicator is off, the NPU is in the slave state or fails to be registered.
OFL
indicator
If the indicator is steady red, the NPU is powered off and can be safely removed.
If the indicator is off, the NPU is working properly.
OFL
button
This button indicates the removal of the NPU. Before removing the NPU, press
and hold the OFL button for 6s until the OFL indicator comes on. Then, you
can remove the NPU.
Specifications
Table 3-21 lists the specifications of the NPU.
Table 3-21 Specifications of the NPU
Item Specification
Silkscreen of the board
name
NPU-120-E
Typical power
consumption
200 W
Heat dissipation 648.9 BTU/hour
Weight 2.62 kg ( 5.78 lb )
Dimensions (H x W x D) 20 mm x 194 mm x 226 mm (0.79 in. x 7.64 in. x 8.90 in. )
Earliest Software Version V800R005C01
3.4.5 Introduction to the NPU-120-E
NOTE
NPU-120-E can be installed in an outdoor cabinet.
The NPU-120-E has a 120-Gbit/s forwarding capability in each direction, and all subcards switch
data through the NPU-120-E.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
3 CX600-X2-M16 Hardware Description
