C.1 Interface Attributes of 10Base-TX/100Base-TX/
1000Base-T-RJ45
Table C-1 lists the interface attributes of 10Base-TX/100Base-TX/1000Base-T-RJ45.
Table C-1 Interface attributes of the 10Base-TX/100Base-TX/1000Base-T-RJ45
Attributes Description
Connector type RJ45
Working mode Half-duplex or full-duplex mode
Cable specification Super category 5 Shielded Twisted Pair (STP) cable is
recommended.
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
C.2 Interface Attributes of 1000Base-X-SFP
Table C-2 lists the interface attributes of 1000Base-X-SFP.
Table C-2 Interface attributes of the 1000Base-X-SFP
Attributes Description
Connector type LC/PC
Interface attributes Compliant with the selected SFP optical module. (For the attributes
of SFP modules, see Table C-3 .)
Working mode Full-duplex
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Table C-3 Attributes of 1000M SFP optical modules
Attributes Description
Transmission
distance
0.5 km
(0.31 mi.)
10 km (6.21
mi.)
40 km
(24.86 mi.)
80 km
(49.71
mi.)
100 km
(62.14 mi.)
