Huawei FusionModule500

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Issue 05 (2019-11-22)
Copyright © Huawei Technologies Co., Ltd.
7
Figure 2-2 42 U Converged Cabinet
Table 2-2 Typical configuration 2
Item
Specifications
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
Power backup time
15–240 minutes
Power distribution
UPS2000-G, battery pack
(optional)/external battery (optional),
PDU5000, and rPDU
Monitoring
ECC800e, T/H sensor, camera (optional),
VCN (optional), door status sensor, smoke
detector, water sensor, pad (optional), WiFi
converter (optional), infrared remote control
module (optional), GSM modem (optional),
NetEco (optional), and LAN switch
(optional)
