Table 3-6 PDU5000 technical specifications
Item
Specifications (3 kVA
UPS)
Specifications (6 kVA
UPS/10 kVA UPS)
Maximum input current
32 A
63 A
Number of phases
1
1
input frequency
50 Hz/60 Hz
50 Hz/60 Hz
Input voltage
220 V/230 V/240 V
220 V/230 V/240 V
Output frequency
50 Hz/60 Hz
50 Hz/60 Hz
UPS input
1-pole 32 A circuit breaker
1-pole 63 A circuit breaker
UPS output
1-pole 32 A circuit breaker
1-pole 63 A circuit breaker
UPS maintenance bypass
2-pole 32 A circuit breaker
2-pole 63 A circuit breaker
Output branch
2 x 16 A/1 P + 3 x 10 A/1 P
4 x 40 A/1 P + 1 x 16 A/1 P
Maximum altitude
4000 m
4000 m
Operating temperature
–5°C to +40°C
–5°C to +40°C
Humidity
5%–95% RH
5%–95% RH
Storage and transportation
temperature
–40°C to +70°C
–40°C to +70°C
Dimensions
430 mm x 450 mm x 130
mm
430 mm x 450 mm x 130
mm
3.2.1.6 rPDU
The rPDU is a basic socket, rather than a monitoring socket.
Table 3-7 rPDU technical specifications
Item
Specifications
(Vertically
Installed
Full-Height
rPDU)
Specifications
(Vertically
Installed
Half-Height
rPDU)
Specifications
(Horizontally
Installed 1 U
rPDU)
Rated current
32 A
32 A
16 A
Input frequency
50 Hz/60 Hz
50 Hz/60 Hz
50 Hz/60 Hz
Input port
Cord end terminal,
no input cable
Cord end terminal,
no input cable
Cord end terminal,
no input cable
