Table 3-48 Technical specifications for the infrared remote control module
Item
Specifications
Number of supported remote control
commands
4 (maximum)
Communication
Interworks with the monitoring system over
Modbus-RTU to implement remote control.
The baud rate can be 9600 bit/s.
Infrared emission distance
≤ 10 m
Power supply
9–16 V DC
Power
≤ 350 mA
Operating temperature
–10°C to +50°C
Operating humidity
5%–95% RH
Protection level
IP20
Indicator
Communication indicator and Run indicator
Color
Black
Address setting
Supports Modbus address setting
3.5 Cable Management
Cables inside cabinets are sorted by cable managers, cable rings, and cable trays. Cable
managers route cables horizontally, cable rings on the cabinet side route cables vertically, and
cable trays route cables from the cabinet front to cabinet rear.
Cable Manager
A cable manager is used for horizontal cabling inside the cabinet.
