Figure 3-35 Cable manager
Table 3-49 Cable manager specifications
Dimensions (H x W x D)
Weight
Space Occupied
43.6 mm x 482.6 mm x 91 mm
0.56 kg
1 U
Cable Ring
A cable ring is installed on a side post in the cabinet to secure vertically routed cables.
Figure 3-36 Cable ring
